217” super large size 1.25MM Small Pitch LED Display Wall,4K UHD, COB protective, ultra slim
217” super large size 1.25MM Small Pitch LED Display Wall,4K UHD, COB protective, ultra slim
Couldn't load pickup availability
Fultape state of the art 217” super large size LED Video Wall Display, native 4K ultra high definition, 1.25mm small pitch,16:9 aspect ratio, COB protective, ultra slim super light weight LED display cabinets for Indoor fixed installation, coming with Novastar LED video processor , MX40 Pro, ideal for various kinds of applications that need 4K UHD ultra clear ultra fine natural picture and video quality. All accessories are included.
Features:
● 217” Super large LED Video Wall Display
● Amazing Ultra HD resolution
● Highly advanced technology of low brightness high grey level, 10,000:1 high contrast ratio
● Wide color gamut, best color uniformity (consistency) and saturation, no tailing, no overlap
● 99.8% High color and brightness uniformity
● Finest natural vivid picture, but eye-care when watching a long time
● 170(H)/170(V) degrees super wide view angle
● 3840Hz~7680Hz ultra high refresh rate to eliminate tailing
● Front accessible cabinet, able to install from front and rear, easy maintenance
● CNC precision manufactured die-casting aluminum cabinet with excellent flatness
● True zero gap Seamless led video wall, tolerance gap between cabinets is less than 0.1mm
● Excellent ventilation with fan-less ultra quiet design
● Ultra-thin cabinet, only 27.5mm thickness
● Extremely light weight cabinet, only 4.5KG
● CE,FCC and Rosh certified, 10,000 hours lifetime
Packing list in details:
● 64* 1.25mm small pixel pitch Led Video Wall Cabinet, 600*337.5mm
● 1 * Navastar MX40 Pro LED video processor
● 1 * Vacuum tool for front maintenance use
● 1 * Rail system for mounting
Specification
| Model | F-I-P1.25UC |
| Product name | COB Ultra-thin extremely light weight fine pixel pitch Indoor full color HD/UHD LED display |
| Pixel | |
| Pixel pitch | 1.25mm |
| Module | |
| Resolution of module | 120*270 |
| Size of module | 150*337.5 |
| Modules/cabinet(L*H) | 4x1 |
| Cabinet | |
| Resolution of cabinet | 480*270 |
| Size of cabinet | 600(L) x 337.5(H)x27.5 (D) |
| Cabinet material | Die casting aluminum alloy |
| Maintenance | Front accessible |
| Thickness of cabinet | 27.5mm |
| Weight of cabinet |
4.5 kg |
| Panel | |
| Pixel density | 640,000dots/m² |
| Resolution of LED wall | Ultra-FHD 4K,3840X2160 |
| Brightness (white balance) |
≥600CD / m² adjustable |
| Panel aspect ratio | 16:9 |
| Contrast ratio | 10,000:1 |
| Color Temperature | 1000K~18500K adjustable |
| Grey scale | 16 bits/65,536 levels |
| Color Uniformity | ≥99.8% |
| View angle | H:170°; V:170° |
| Optimal viewing distance | 2-20M |
| Average power consumption/sqm | 80~150Watts |
| Max. power consumption |
420Watts /m2 |
| Refresh rate | ≥3840HZ |
| Frame rate | 50-60Hz |
| IP rating |
IP31 Waterproof & dustproof ( front and back ) |
| Control | |
| Scan rate | 1/60scan |
| Operation | |
| Power supply | 90~264 V AC , 47~63 Hz |
| MTBF | ≥5,000 hours |
| Lifespan | 75,000 ~100,000 hours |
| Out of control rate | <0.0001 |
| Operation temperature | Minus 20℃~60℃ |
| Operation humidity | 10%~85%RH |
| Storage & Application | |
| Storage temperature | Minus 40℃~85℃ |
| Storage humidity | 30%~60%RH |
| Warranty | 3 years |
| Certifications | CE, FCC,CCC |
Downloads
Fultape 4rd COB fine pitch UHD LED display datasheet
